SRP:$
< Roll over image to zoom in
KEY FEATURES
& Superior holding torque
& Incredible efficiency and low power consumption
& CNC Machined aluminum case for exceptional cooling
& Supporting SXR, SUR, SR, SFR multiple ultra high speed modes
& 25T output shaft
& 1-Year limited warranty
| Item no | 6.0V | 7.4V | 8.4V | Gear | Motor | Case | Dimension (mm) | Weight (g) | |||
| Speed: sec/60° | Torque: kg-cm/oz-in | Speed: sec/60° | Torque: kg-cm/oz-in | Speed: sec/60° | Torque: kg-cm/oz-in | ||||||
| T45 | 0.16 | 36.0/499.9 | 0.14 | 40.0/555.5 | 0.13 | 45.0/625.0 | Steel & Aluminum | Coreless | All-metal | 40.7*20.5*39.0 | 81.0 |
Application :
Air plane
1/10 Crawler
1/8 Crawler
PRODUCT SPECIFICATIONS
type: digital
bearing: dual
motor type: coreless
gear type: metal
gear material: steel & alu
control system: pulse width control
working frequency: 1520μs / 330hz
operating voltage: dc 6.0-8.4v
operating temperature range: -10 to +60 degree
operating speed (6.0v): 0.16 sec/60 degrees at no load
operating speed (7.4v): 0.14 sec/60 degrees at no load
operating speed (8.4v): 0.13 sec/60 degrees at no load
stall torque (6.0v): 30.0 kg/cm (499.9 oz/in)
stall torque (7.4v): 40.0 kg/cm (555.5 oz/in)
stall torque (8.4v): 45.0 kg/cm (625.0 oz/in)
potentiometer drive: direct drive
dimensions: 40.7 x 20.5 x 39.0 mm / 1.60 x 0.81 x 1.54 in
weight: 81.0 g (2.86 oz)
connector wire length: jr 300 mm
SRT SERVO OVERVIEW
All SRT servos are available to be customized by OEM service if you need, please feel free to contact us.
