< Roll over image to zoom in
KEY FEATURES
& Incredible efficiency and low power consumption
& NMB dual main bearings
& Waterproof function
& 25T output shaft
& 1-Year limited warranty
| Item no | 6.0V | 7.4V | 8.4V | Gear | Motor | Case |
Dimension (mm) |
Weight (g) | |||
|
Speed: sec/60° |
Torque: kg-cm/oz-in |
Speed: sec/60° |
Torque: kg-cm/oz-in |
Speed: sec/60° |
Torque: kg-cm/oz-in | ||||||
| W45 | 0.20 | 34.0/472.2 | 0.19 | 40.0/555.5 | 0.18 | 45.0/624.9 | Titanium & Steel | Coreless | All-metal | 40.7*20.5*38.6 | 82.5 |
Application :
1/10 Crawler
1/8 Crawler
1/8 Electric Buggy
PRODUCT SPECIFICATIONS
type: digital
bearing: dual
motor type: coreless
gear type: metal
gear material: titanium & steel
control system: pulse width control
working frequency: 1520μs / 330hz
operating voltage: dc 6.0-8.4v
operating temperature range: -10 to +60 degree
operating speed (6.0v): 0.20 sec/60 degrees at no load
operating speed (7.4v): 0.19 sec/60 degrees at no load
operating speed (8.4v): 0.18 sec/60 degrees at no load
stall torque (6.0v): 34.0 kg/cm (472.2 oz/in)
stall torque (7.4v): 40.0 kg/cm (555.5 oz/in)
stall torque (8.4v): 45.0 kg/cm (624.9 oz/in)
potentiometer drive: direct drive
dimensions: 40.7x20.5x38.6 mm / 1.60x0.81x1.52 in
weight: 82.5 g (2.91 oz)
connector wire length: jr 360 mm
SRT SERVO OVERVIEW
All SRT servos are available to be customized by OEM service if you need, please feel free to contact us.
