SRP:$
< Roll over image to zoom in
KEY FEATURES
& Superior holding torque
& Incredible efficiency and low power consumption
& CNC machined aluminum case for exceptional cooling
& Supporting SXR, SUR, SR, SFR multiple ultra high speed modes
& 25T output shaft
& 1-Year limited warranty
| Item no | 6.0V | 7.4V | 8.4V | Gear | Motor | Case | Dimension (mm) | Weight (g) | |||
| Speed: sec/60° | Torque: kg-cm/oz-in | Speed: sec/60° | Torque: kg-cm/oz-in | Speed: sec/60° | Torque: kg-cm/oz-in | ||||||
| T75 | 0.16 | 55.0/763.8 | 0.14 | 60.0/833.2 | 0.12 | 70.0/972.1 | Titanium & Steel | Brushless | All-metal | 40.7*20.5*39.0 | 83.0 |
Application :
1/10 Crawler
1/8 Crawler
1/8 Nitro Buggy
1/8 Electric Buggy
PRODUCT SPECIFICATIONS
type: digital
bearing: dual
motor type: brushless
gear Type: metal
gear material: titanium & steel
control system: pulse width control
working frequency: 1520μs / 330hz
operating voltage: dc 6.0-8.4v
operating temperature range: -10 to +60 degree
operating speed (6.0v): 0.16 sec/60 degrees at no load
operating speed (7.4v): 0.14 sec/60 degrees at no load
operating speed (8.4v): 0.12 sec/60 degrees at no load
stall torque (6.0v): 55.0 kg/cm (763.8 oz/in)
stall torque (7.4v): 60.0 kg/cm (833.2 oz/in)
stall torque (8.4v): 70.0 kg/cm (972.1 oz/in)
potentiometer drive: direct drive
dimensions: 40.7 x 20.5 x 39.0 mm / 1.60 x 0.81 x 1.54 in
weight: 83.0 g (2.93 oz)
connector wire length: jr 300 mm
SRT SERVO OVERVIEW
All SRT servos are available to be customized by OEM service if you need, please feel free to contact us.
